| Input specification | ||||
| Volatage | DA | 3~32VDC | AA | 40~480VAC |
| Maximum input current | 15mA | 12mA | ||
| Ensure on voltage | 3.5VDC | 40VAC | ||
| Ensure turn-off voltage | 1.5VDC | 30VAC | ||
| Output specification | ||||
| Output voltage range | 40~480VAC | |||
|
Peak voltage |
800v | |||
| Maximum load current | 25A、40A、60A、80A、100A | |||
| OFF state leakage current | 8mA rms | |||
| ON state saturation voltage drop | 1.5V | |||
| Other characteristics | ||||
| Dimension（mm） | 62*45*29 | |||
| Weight | 105g | |||
| Insulation resistance | Min 50MΩ | |||
| Crushing strength | 2500V rms | |||
| Operating temperature | ’-20℃~80℃ | |||
| PBT flame retardant and specially designed shell, oxygen-free copper main electrode, low contact resistance. |
 |
|
Vacuum sintering process with bare sheet, low thermal resistance. |
|
|
High thermal conductivity double-sided copper DBC board insulation, fast thermal conductivity. |
|
|
Dual-channel SCR anti-parallel structure, high current carrying capacity. |
|
|
Dynamic and static parameters of the complete test means, quality assurance. |
|
|
Dynamic and static parameters of the complete test means, quality assurance. |
